2023 | Professional

MUSE Design Awards Silver Winner

Integrated AC Servo Waterproof Motor

Entrant Company

SHENZHEN JUST MOTION CONTROL ELECTROMECHANICS CO.,LTD.

Category

Product Design - Industrial

Client's Name

Li Zhangfeng

Country / Region

China

The integrated AC servo waterproof motor is an advanced motor product that boasts efficiency, stability, and waterproof and dust-proof functions. It is successfully integrated with encoder, driver, and heat sink through innovative design. This not only saves installation costs and equipment space but also achieves an IP65 protection rating, making it dustproof and waterproof. It can be widely used in the automation field, including CNC machine tools, printing and packaging machinery, textile machinery, robots, and automated production lines.

The motor adopts a full curved shape with an elegant bullet-head design that not only looks aesthetically pleasing but also adheres to ergonomic principles, providing a comfortable grip. The aluminum alloy rear cover offers superior heat dissipation, and the fully enclosed design achieves an IP65 waterproof rating, combining both aesthetics and practicality.

The motor driver adopts a dual-chip platform with ARM and FPGA, featuring optimized current loop design. This helps deliver a high dynamic response, extremely short tuning time, smooth operation, and minimal vibration during stops. Besides, it also supports standard 100M full-duplex EtherCAT bus network interface and CoE communication protocol, as well as the standard CIA402 motion control protocol.

The integrated AC servo waterproof motor revolutionizes the traditional integrated appearance with its innovative external design. Additionally, aviation plug connectors are incorporated into the product, ensuring more stable and reliable communication. The product also features automatic gain adjustment modules and multiple sets of notch filters which greatly boosts equipment stability and adaptability.

The high efficiency and reliability of the integrated AC servo waterproof motor, combined with its wide range of applications, make it a key driver for industrial development. It offers industrial customers a new choice that not only improves production efficiency and quality but also reduces maintenance costs and the risk of equipment damage. Moreover, the motor is made of aluminum alloy material which is recyclable, aligning with green development philosophy.

Credits

Li Zhangfeng
